研华工控主板SIMB-986-NL2A1

Features
SIMB-986
ƒ Intel® 10th generation Core™ i9/i7/i5/i3 &Pentium®/Celeron® processor with
H420E chipset
ƒ Dual channel (Non-ECC) DDR4 2400/2666/2933 up to 64 GB
ƒ Support VGA and HDMI,DP ,LVDS display
ƒ 2 M.2 MSATA, 2 SATA 3.0, 6 USB 3.2, 4 USB2.0, 2 2.5GbE LAN, 2 RS232/
RS422/RS485 and 7 RS232, 1 RS485
ƒ 1 PCIe x16 and 3 PCIe x1 and 3 PCI expansion slots
ƒ Support TPM
ƒ Supports Win10 / Win11
